Alumil Supreme SD77 System
SUPREME SD77 is ALUMIL’s new innovative entrance door with unique form and functions designed to provide efficiency, durability and fitness. SD77 offers flexibility in design and with its multiple typologies provides endless possibilities to fit every structural span required. With its modern, sleek flat designs and aesthetic touches has the ability to be combined with either aluminum panels or grazing infills without sacrificing its finesse. A true technological advancement offering optimum performance and sustainable building.
Contact Sales Agent ❯
Technical Details
- Sleek look in the system’s 77mm depth.
- Low threshold of only 22mm height with slip resistant design.
- High level of thermal insulation and water tightness.
- Designed to fit different solutions.
- Wide variety of security locks and hinges (concealed, barrel or surface mounted).
- Ideal entrance door for S77 window series
| PROFILE CHARACTERISTICS | |
| Frame depth | 77 mm |
| Sash depth | 77 mm |
| Minimum visible width | 154,5 mm |
| Minimum visible width (Τ-Profile) | 76 mm |
| Sash mechanism weight limit | 180 Kg |
| Glass thickness | up to 68 mm |
| Cross section thickness | 1,3 up to 2 mm |
| SYSTEM CHARACTERISTICS | |
| Type of system | Insulated |
| UD | 0,7 W/m2K |
| Exterior aesthetics | Flat |
| Glazing method | Aluseal system |
| Type of thermal insulation | 40 mm polyamide |
| Mechanism | Perimetrical locking mechanism |
| Typologies | Single leaf door, Double leaf door, Single leaf door with insulation panel, Double leaf door with insulation panel, Single leaf door with insulation panel and fixed light, Single leaf door with insulation panel, fanlight and fixed lights, Single leaf door with fixed light, Single leaf door with fanlight and fixed lights |
